| No. | Size | Tail / Pitch / Position (mm) |
Dimensions (mm) E:Out / V:View / A:Act |
Glass Thickness / Total Thickness (mm) |
Part Number | Controller |
|---|---|---|---|---|---|---|
| 1 | 4.3 | 80/1/Lower Side | E : 105.4 x 67.83 V : 97.54 x 55.86 A : 95.54 x 54.36 |
1.1/1.4 |
LST-043WC080C |
TSC-52/RU-F-S1,
TSC-54/RU-F
|
| 2 | 5.7 | 80/1/Left Side | E : 131.4 x 103 V : 119.7 x 90.9 A : 115.7 x 86.9 |
1.1/1.4 |
LST-057C080C |
TSC-52/RU-F-S1,
TSC-54/RU-F
|
| 3 | 6.5 | 80/1/Left Side | E : 147.3 x 114.3 V : 136.98 x 103.86 A : 132.98 x 99.86 |
1.1/1.4 |
LST-065C080C |
TSC-52/RU-F-S1,
TSC-54/RU-F
|
| 4 | 7w | 80/1/Left Side | E : 165.15 x 104 V : 155.9 x 94.94 A : 152.9 x 91.94 |
1.1/1.4 |
LST-070WC080C |
TSC-52/RU-F-S1,
TSC-54/RU-F
|
| 5 | 8.4 | 80/1/Left Side | E : 185.6 x 143.3 V : 174.9 x 132.3 A : 170.9 x 128.3 |
1.8/2.1 |
LST-084C080C |
TSC-52/RU-F-S1,
TSC-54/RU-F
|
| 6 | 10.1w | 80/1/Left Side | E : 234.7 x 153 V : 221.46 x 140.1 A : 217.46 x 136.1 |
1.8/2.1 |
LST-101WC080C |
TSC-52/RU-F-S1,
TSC-54/RU-F
|
| 7 | 10.1w | 80/1/Left Side | E : 236.27 x 143 V : 227.22 x 129.78 A : 223.22 x 125.78 |
1.8/2.1 |
LST-101WC080C-WS |
TSC-52/RU-F-S1,
TSC-54/RU-F
|
| 8 | 10.4 | 80/1/Left Side | E : 227.6 x 175.4 V : 215.7 x 162.9 A : 211.7 x 158.9 |
1.8/2.1 |
LST-104C080C |
TSC-52/RU-F-S1,
TSC-54/RU-F
|
| 9 | 12.1 | 80/1/Left Side | E : 263 x 201 V : 250.5 x 189 A : 246.5 x 185 |
1.8/2.1 |
LST-121C080C |
TSC-52/RU-F-S1,
TSC-54/RU-F
|
| 10 | 12.1w | 80/1/Left Side | E : 278.4 x 180.7 V : 265.62 x 167.7 A : 261.62 x 163.7 |
1.8/2.1 |
LST-121WC080C |
TSC-52/RU-F-S1,
TSC-54/RU-F
|
| 11 | 15 | 80/1/Left Side | E : 328 x 252 V : 308.63 x 232.6 A : 304.63 x 228.6 |
1.8/2.1 |
LST-150C080C |
TSC-52/RU-F-S1,
TSC-54/RU-F
|
| 12 | 15.6w | 80/1/Left Side | E : 361.5 x 210.2 V : 348.73 x 198.04 A : 344.73 x 194.04 |
1.8/2.1 |
LST-156WC080C |
TSC-52/RU-F-L1,
TSC-54/RU-F
|
| 13 | 18.5w | TBD// | E : TBD x V : TBD x A : TBD x |
TBD/ |
LST-185WC080C |
TSC-52/RU-F-L1,
TSC-54/RU-F
|
| 14 | 19 | TBD// | E : TBD x V : TBD x A : TBD x |
TBD/ |
LST-190C080C |
TSC-52/RU-F-L1,
TSC-54/RU-F
|
| 15 | 21.5w | TBD// | E : TBD x V : TBD x A : TBD x |
TBD/ |
LST-215WC080C |
TSC-52/RU-F-L1,
TSC-54/RU-F
|
Why Choose DMC's Analog Resistive Touchscreens
-
![Rock-Solid Stability via Pressure Sensing Even in High-Noise Environments]()
-
Rock-Solid Stability via Pressure Sensing Even in High-Noise Environments
Even in harsh high-noise environments near operating motors or high-frequency equipment, pressure-based touch detection eliminates false inputs. It delivers rock-solid operational stability in any installation environment, reducing the risk of operator error and providing a reliable interface that keeps production lines running without interruption.
-
![Resistant to Water and Contaminants for Worry-Free Operation]()
-
Resistant to Water and Contaminants for Worry-Free Operation
Unlike capacitive touch screens, water droplets or oil on the surface will not trigger unintended touches, preventing accidental operation and equipment downtime. It can be safely wiped down and sanitized with alcohol during routine cleaning, achieving both hygiene and smooth, highly efficient field operations.
-
![Smooth Touch Operation with Gloves or Pens]()
-
Smooth Touch Operation with Gloves or Pens
Effortless touch control is supported across all glove types—from rubber and leather to heavy cold-weather gloves. It also responds accurately to fine inputs made with fingernails or dedicated styluses, preventing miskeys and providing a stress-free user experience that reduces operator workload without slowing down workflow.
-
![Anti-Glare Film Applied to Reduce Glare]()
-
Anti-Glare Film Applied to Reduce Glare
The surface ITO film features anti-glare coating to suppress light reflections and glare. Clear film option is also available upon customization for applications requiring crisp, high-clarity visuals, allowing you to choose the optimal specification for your operating environment and application.
-
![High Reliability Proven by 10 Million Tap Tests]()
-
High Reliability Proven by 10 Million Tap Tests
Engineered for long-term durability in severe operating conditions, this touch panel passes 3 to 10 times more tap cycles than standard touch screens. It significantly cuts replacement frequency and maintenance costs, providing long-lasting reliability in demanding setups such as factory floors and outdoor kiosks.
-
![Smooth & High Durability Minimizing Wear and Friction]()
-
Smooth & High Durability Minimizing Wear and Friction
Micro-dot spacers effectively reduce friction between internal film layers. While ensuring outstanding durability, the ultra-small, unobtrusive dots maintain high visual clarity. Even after long-term use, legibility of text and graphics remains uncompromised for comfortable touch operation.
-
![Highly Reliable Durability Polyimide FPC Adopted]()
-
Highly Reliable Durability Polyimide FPC Adopted
Features a polyimide FPC (Flexible Printed Circuit) known for superior moisture resistance. Gold-plated contacts resist aging and oxidation, ensuring stable conductivity and high connection reliability even in harsh, high-humidity environments for long-term confidence.
